22216E/C3 SKF
$1,426.74
In stock
SKU
22216E/C3 SKF
Suffix description
- E d ≤65mm, Two Window-Type Steel Cages, Flangeless Inner Ring And Guide Centered On The Inner Ring. When d >65 mm Same As <65mm But Guide Ring Centered On The Cages
- C3 Internal Clearance Larger Than Normal
Product description
The 22216E/C3 SKF is a spherical roller bearing with an open design. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
Specifications
- Brand SKF
- Item Number 22216E/C3 SKF
- EAN 7316576652509
- Category Spherical Roller Bearing
Weight and Dimensions
- Inner (d) MM 80
- Outer (D) MM 140
- Width (B) MM 33
- Inner (d) Inch 3.1496
- Outer (D) Inch 5.5118
- Width (B) Inch 1.2992
- Weight (kg) 1.97
Product Properties
- Bore C - Cylindrical Bore
- Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
- Seal No Seal
- Cage Type S - Steel or Standard Cage
- Radial Internal Play C3 Internal Play (Higher than Cn)
- Precision Standard Precision
- Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
- Vibrating Screen Execution Non Vibrating Screen Execution
