22217EK SKF
$1,589.28
In stock
SKU
22217EK SKF
Suffix description
- E d ≤65mm, Two Window-Type Steel Cages, Flangeless Inner Ring And Guide Centered On The Inner Ring. When d >65 mm Same As <65mm But Guide Ring Centered On The Cages
- K Tapered Bore, Taper 1:12
Product description
The 22217EK SKF is a spherical roller bearing with an open design. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
Specifications
- Brand SKF
- Item Number 22217EK SKF
- EAN 7316571008714
- Category Spherical Roller Bearing
Weight and Dimensions
- Inner (d) MM 85
- Outer (D) MM 150
- Width (B) MM 36
- Inner (d) Inch 3.3465
- Outer (D) Inch 5.9055
- Width (B) Inch 1.4173
- Weight (kg) 2.3
Product Properties
- Bore K - 1:12 Tapered Bore (Standard for Most Types)
- Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
- Seal No Seal
- Cage Type S - Steel or Standard Cage
- Radial Internal Play Cn Normal Internal Play
- Precision Standard Precision
- Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
- Vibrating Screen Execution Non Vibrating Screen Execution
