22220E SKF
$2,558.78
In stock
SKU
22220E SKF
Suffix description
- E d ≤65mm, Two Window-Type Steel Cages, Flangeless Inner Ring And Guide Centered On The Inner Ring. When d >65 mm Same As <65mm But Guide Ring Centered On The Cages
Product description
The 22220E SKF is a spherical roller bearing with an open design. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.
Specifications
- Brand SKF
- Item Number 22220E SKF
- EAN 7316571167947
- Category Spherical Roller Bearing
Weight and Dimensions
- Inner (d) MM 100
- Outer (D) MM 180
- Width (B) MM 46
- Inner (d) Inch 3.937
- Outer (D) Inch 7.0866
- Width (B) Inch 1.811
- Weight (kg) 4.69
Product Properties
- Bore C - Cylindrical Bore
- Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
- Seal No Seal
- Cage Type S - Steel or Standard Cage
- Radial Internal Play Cn Normal Internal Play
- Precision Standard Precision
- Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
- Vibrating Screen Execution Non Vibrating Screen Execution
